DB-2000
2U Video Wall Controller - max 12 HD inputs × 8 screens
DB-3000
3U Video Wall Controller - max 24 HD inputs × 8 screens
DB-6000
6U Video Wall Controller - max 32 HD inputs × 16 screens
DB-8000
8U Video Wall Controller - max 40 HD inputs × 36 screens
DB-12000
12U Video Wall Controller - max 84 HD inputs × 72 screens
DB-24000
24U Video Wall Controller - max 152 HD inputs × 144 screens
DB-IC-Q-DVI
Quad-Channel DVI
DB-IC-D-DLDVI
Dual-Channel Dual-Link DVI
DB-IC-Q-VGA Quad-Channel VGA
DB-IC-Q-HDMI
Quad-Channel HDMI
DB-IC-Q-CVBS Quad-Channel CVBS
DB-IC-Q-YPbPr
Quad-Channel YPbPr
DB-IC-Q-SDI
Quad-Channel SDI
DB-IC-Q-HDBT Quad-Channel HDBaseT
DB-DC-D-IP
Dual-Channel IP Streaming Decoder Card
DB-OC-Q-DVI
Quad-Channel DVI
DB-OC-Q-HDMI
Quad-Channel HDMI
DB-OC-4K-HDMI
Single Channel 4K HDMI
DB-OC-Q-HDBT Quad-Channel HDBaseT
DB-FC-CMC
Confidence Monitoring Card
DB-FC-NPC
Network Previewing Card
DB-FC-VNC
Remote Desktop Capturing VNC Card
DB-EAV201-H Dual Channels IP H.264 Encoder
Video Wall Controller Input Cards
Video Wall Controller Output Cards
System Cards
Video Wall Controllers
Powerful Video Wall Controllers
Spitzentechnologie bei Videoverarbeitung und -steuerung sowie ein einzigartiges Design von Hot-Swap-fähigen
Ein- und Ausgangskarten bietet Integratoren erhebliche Vorteile bei der Systemimplementierung und -leistung. Bis
zu 152 HD Eingangssignale mit maximaler Eingangsauflösung von 4K / UltraHD und Ausgangsauflösungen von
3840x2160 werden vom Videowall-Controller unterstützt. Die Videowall-Controller wandeln alle Videoquellen
einfach zu beweglichen und skalierbaren Fenstern zur Anzeige auf mehreren, einzelnen Anzeigegeräten ohne
Leistungseinbußen.
Leading edge technology in video processing, control and a unique design of hot-swappable input/output cards
provides integrators with significant benefits for system implementation and performance. Up to 152 high definition
input signals can be supported by the Video Wall Controller with maximum input resolution of 4Kx4K, and maximum
output resolution of 3840x2160. The Video Wall Controllers easily incorporate all video sources to moveable and
scalable windows for deployment to multiple display devices without performance compromise
.
Videowall
Controllers
