mediahub™ zur On-Table Installation inkl. Luxi™ Presenter
• “All-in-one“ Tischanschlussfeld für Strom, Netzwerk, A/V, etc
• Integrierter Luxi™ Presenter LU-TPR-150CR
• Ausführung zur On-Table Installation
• Inkl. austauschbarer Steckdosen, 2x USB, 1x Ethernet und leichtgängigem
Mechanismus
mediahub™ for on-table installations incl. Luxi™ Presenter
• All-in-one desk connector panel for power, Ethernet, A/V, etc.
• Integrated Luxi™ Presenter LU-TPR-150CR
• Model for on-table installations
• Incl. replaceable power outlets, 2x USB, 1x Ethernet and smooth, frustration-free
mechanism
mediahub™ zur On-Table Installation
inkl. Luxi™ Presentation Switcher
• “All-in-one“ Tischanschlussfeld für Strom, Netzwerk, A/V, etc
• Integrierter Luxi™ Presentation Switcher LU-SHD-310SM
• Ausführung zur On-Table Installation
• Inkl. austauschbarer Steckdosen, 2x USB, 1x Ethernet und leichtgängigem
Mechanismus
mediahub™ for on-table installations
incl. Luxi™ Presentation Switcher
• All-in-one desk connector panel for power, Ethernet, A/V, etc.
• Integrated Luxi™ Presentation Switcher LU-SHD-310SM
• Model for on-table installations
• Incl. replaceable power outlets, 2x USB, 1x Ethernet and smooth, frustration-free
mechanism
Artikel-Nr. | Item No.
Eingänge | Inputs
Ausgänge | Outputs
MHUB-ENC100 inkl.
MHUB-CART-TPR150
2x Steckdosen (intl.), 2x USB Schnellladeports,
1x HDMI, 1x VGA, 1x 3,5mm Stereo Audio,
1x DisplayPort, 1x Daisy-Chain Cat (RJ45),
1x Ethernet (RJ45), 1x RS-232 (Phoenix), 1x „Show Me“
1x Daisy-Chain Cat (RJ45)
Artikel-Nr. | Item No.
Eingänge | Inputs
Ausgänge | Outputs
MHUB-ENC100 inkl.
MHUB-CART-SHD310
2x Steckdosen (intl.), 2x USB Schnellladeports,
1x HDMI, 1x VGA, 1x 3,5mm Stereo Audio,
1x DisplayPort, 1x RS-232 (Phoenix), 1x "Show Me"
2x HDMI, 1x Stereo Audio (Phoenix)
HDMIOUT
12VDCA
1 2
+ G
+ - G + -
RS232 CC INPUT
TxRxGV
V H D G
AUDIOOUT
12VDC
+ G
RS232 CC INPUT
TxRxGV
ETHERNET
100s IN 100s IN
V H D G
*available colours
A
C G S
*available colours
A
C G S
